how to install and configure openvpn on rhel 9/8

OpenVPN on Red Hat Enterprise Linux 9/8 delivers secure, flexible remote access. The process below covers packages, PKI, server configuration, firewall, and client profiles using Easy-RSA 3. Commands are safe to copy, tuned for SELinux, and optimized for UDP performance and modern ciphers.

Step 1: Verify OS, network, and update

Confirm the platform, refresh repositories, and prepare the system for OpenVPN and PKI tooling.

cat /etc/redhat-release
ip a
getenforce
dnf -y update

Optional output example:

Red Hat Enterprise Linux release 9.x (Plow)
Enforcing

Step 2: Enable EPEL and CodeReady/CRB repositories

OpenVPN and Easy-RSA live in EPEL and require CodeReady Builder (or CRB on derivatives). Enable the right channels for RHEL 9/8.

source /etc/os-release

# Enable EPEL
dnf -y install epel-release

# Enable CodeReady Builder (RHEL)
if [[ "$ID" = "rhel" && "$VERSION_ID" =~ ^9 ]]; then
  subscription-manager repos --enable codeready-builder-for-rhel-9-$(arch)-rpms
elif [[ "$ID" = "rhel" && "$VERSION_ID" =~ ^8 ]]; then
  subscription-manager repos --enable codeready-builder-for-rhel-8-$(arch)-rpms
fi

# Enable CRB/Powertools (Rocky/Alma/CentOS Stream fallback)
if command -v dnf &>/dev/null; then
  dnf config-manager --set-enabled crb || dnf config-manager --set-enabled powertools || true
fi

Step 3: Install OpenVPN, Easy-RSA, and firewalld

Install the VPN daemon, certificate tools, and firewall. Ensure firewalld runs persistently.

dnf -y install openvpn easy-rsa firewalld policycoreutils-python-utils
systemctl enable --now firewalld

Step 4: Initialize PKI with Easy-RSA 3

Create the certificate authority, server certificate, Diffie-Hellman parameters, CRL, and a tls-crypt key. Secure key material and place it under /etc/openvpn.

mkdir -p /etc/openvpn/server /etc/openvpn/pki
cp -r /usr/share/easy-rsa /etc/openvpn/
cd /etc/openvpn/easy-rsa/3

./easyrsa init-pki
# Set a concise CA name when prompted
./easyrsa build-ca nopass

# Server cert (CN: server)
./easyrsa build-server-full server nopass

# DH params and CRL
./easyrsa gen-dh
./easyrsa gen-crl

# tls-crypt key for control channel protection
openvpn --genkey secret /etc/openvpn/server/tc.key

# Move PKI artifacts to /etc/openvpn/pki
cp -a pki/* /etc/openvpn/pki/

# Secure permissions
chmod 600 /etc/openvpn/pki/private/*.key /etc/openvpn/server/tc.key
chown -R root:root /etc/openvpn/pki /etc/openvpn/server

Step 5: Create a secure server configuration

Define UDP, TUN, topology, secure ciphers, and push routes/DNS for clients. The config references the PKI and tls-crypt key.

cat >/etc/openvpn/server/server.conf <<'EOF'
port 1194
proto udp
dev tun

user nobody
group nobody
persist-key
persist-tun
topology subnet

server 10.8.0.0 255.255.255.0
ifconfig-pool-persist /var/lib/openvpn/ipp.txt

push "redirect-gateway def1 bypass-dhcp"
push "dhcp-option DNS 1.1.1.1"
push "dhcp-option DNS 8.8.8.8"

keepalive 10 60
explicit-exit-notify 1

# Modern crypto
cipher AES-256-GCM
data-ciphers AES-256-GCM
ncp-ciphers AES-256-GCM
auth SHA256
remote-cert-tls client

# PKI paths
ca /etc/openvpn/pki/ca.crt
cert /etc/openvpn/pki/issued/server.crt
key /etc/openvpn/pki/private/server.key
dh /etc/openvpn/pki/dh.pem
crl-verify /etc/openvpn/pki/crl.pem
tls-crypt /etc/openvpn/server/tc.key

# Logs
status /var/log/openvpn-status.log
log-append /var/log/openvpn.log
verb 3
EOF

Step 6: Enable IP forwarding

Allow the kernel to route traffic from VPN clients to the LAN/Internet. Persist the setting across reboots.

sysctl -w net.ipv4.ip_forward=1
sysctl -w net.ipv6.conf.all.forwarding=1

cat >/etc/sysctl.d/99-openvpn.conf <<'EOF'
net.ipv4.ip_forward = 1
net.ipv6.conf.all.forwarding = 1
EOF

sysctl --system

Step 7: Open firewall and configure NAT

Open UDP/1194 and enable masquerading so client traffic can exit via the server’s public interface.

firewall-cmd --permanent --add-port=1194/udp
firewall-cmd --permanent --add-masquerade
firewall-cmd --reload

# Optional: restrict VPN source network if you use zones
# firewall-cmd --permanent --zone=public --add-source=10.8.0.0/24
# firewall-cmd --reload

Step 8: Start and enable the OpenVPN server

Use the templated systemd unit. Validate status and logs to confirm a clean start.

systemctl enable --now [email protected]
systemctl status [email protected] --no-pager
tail -n 50 /var/log/openvpn.log

Expected status snippet:

Active: active (running)
UDPv4 link local (bound): [AF_INET][undef]:1194
Initialization Sequence Completed

Step 9: Create client certificates

Issue per-user certificates with Easy-RSA. Protect private keys. Use passwordless or passphrase as your policy dictates.

cd /etc/openvpn/easy-rsa/3
./easyrsa build-client-full alice nopass

# Collect required files for alice:
#  - /etc/openvpn/pki/ca.crt
#  - /etc/openvpn/pki/issued/alice.crt
#  - /etc/openvpn/pki/private/alice.key
#  - /etc/openvpn/server/tc.key (tls-crypt)

Step 10: Build an inline .ovpn profile

Create a single-file client profile embedding CA, cert, key, and tls-crypt. Replace YOUR_SERVER_IP with the server’s public IP or DNS.

cat >alice.ovpn <<'EOF'
client
dev tun
proto udp
remote YOUR_SERVER_IP 1194
resolv-retry infinite
nobind
persist-key
persist-tun
remote-cert-tls server

cipher AES-256-GCM
auth SHA256
verb 3

<ca>
# paste /etc/openvpn/pki/ca.crt
</ca>
<cert>
# paste /etc/openvpn/pki/issued/alice.crt
</cert>
<key>
# paste /etc/openvpn/pki/private/alice.key
</key>
<tls-crypt>
# paste /etc/openvpn/server/tc.key
</tls-crypt>
EOF

Step 11: Connect and validate routing

Test with the official OpenVPN client (Windows/macOS/Linux). Verify tunnel creation, assigned IP, and Internet egress via the server.

# On Linux client after connecting:
ip a show tun0
curl -4 ifconfig.me
# On server, watch logs:
journalctl -u openvpn-server@server -f

Step 12: SELinux and file contexts

Default paths work under Enforcing. If you use custom directories, label them correctly and restore contexts.

restorecon -Rv /etc/openvpn

# If using a nonstandard path (example: /opt/openvpn)
semanage fcontext -a -t openvpn_etc_t "/opt/openvpn(/.*)?"
restorecon -Rv /opt/openvpn

Step 13: Common maintenance and troubleshooting

Rotate CRLs, revoke users, and inspect connectivity. Use these quick checks before deeper packet captures.

# Revoke a client and update CRL
cd /etc/openvpn/easy-rsa/3
./easyrsa revoke alice
./easyrsa gen-crl
cp -f pki/crl.pem /etc/openvpn/pki/crl.pem
systemctl reload openvpn-server@server

# Connectivity checks
ss -lunpt | grep 1194
firewall-cmd --list-all
tcpdump -ni any udp port 1194

Result: a secure, performant OpenVPN server on RHEL 9/8 with modern crypto, proper routing, and clean SELinux integration.For more guides and support, visit dropvps.com
