How to get proxy settings in cmd?

Creating your own proxy server can be a great way to learn about networking and enhance your internet privacy or bypass restrictions. Here’s a step-by-step guide on how to set up a basic proxy server using various methods. We’ll cover a popular approach using Squid, a widely used proxy server software, as well as a simpler method using CCProxy for Windows users.

Method 1: Setting Up a Proxy Server with Squid (Linux)

Step 1: Install Squid

Update your package list:

sudo apt update

Install Squid:

sudo apt install squid

Step 2: Configure Squid

Backup the default configuration:

sudo cp /etc/squid/squid.conf /etc/squid/squid.conf.backup

Edit the configuration file:

sudo nano /etc/squid/squid.conf

Basic Configuration: In the configuration file, you can set up rules for access control and specify the port on which Squid will listen (default is 3128).

To allow access from your local network, add a line like this (replace 192.168.1.0/24 with your local network address):

acl localnet src 192.168.1.0/24
http_access allow localnet

You can also change the default port if needed:

http_port 3128

Save and exit: After making your changes, save the file and exit.

Step 3: Start and Enable Squid Service

Start the Squid service:

sudo systemctl start squid

Enable it to start on boot:

sudo systemctl enable squid

Step 4: Test Your Proxy Server

• To test your proxy server, configure your web browser or system to use the IP address of the machine running Squid and the port you configured (default is 3128).

Method 2: Setting Up a Proxy Server with CCProxy (Windows)

Step 1: Download and Install CCProxy

1. Download CCProxy from the official website: CCProxy.
2. Install CCProxy by following the installation wizard.

Step 2: Configure CCProxy

1. Open CCProxy after installation.
2. Configure the Listening Port: By default, CCProxy uses port 808. You can change this in the settings if needed.
3. Set User Access: In the “Account” tab, you can configure user access settings, allowing specific users or IP addresses to use the proxy.
4. Configure the Proxy Type: You can specify whether it will be an HTTP, FTP, or SOCKS proxy.

Step 3: Start the Proxy Server

1. Click on the “Start” button in CCProxy to start the proxy server.
2. You can monitor the traffic and connected users from the CCProxy interface.

Step 4: Test Your Proxy Server

• Similar to the Squid setup, configure your web browser or system to use the IP address of the machine running CCProxy and the port you set (default is 808).

Setting up your own proxy server can be a rewarding project that enhances your understanding of networking. Whether you choose Squid for a robust Linux-based solution or CCProxy for a simpler Windows-based setup, each method provides a way to control and monitor internet traffic effectively. After setting it up, make sure to test it thoroughly to ensure it meets your needs.
